SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–17
Bulk Insert
Channels
Assignment Command:
Response:
Status:
Response: >add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
>add/BICA_ii;cc_ii;cc_ii;cc_ii;cc......'cr''lf']
Where:
ii = 1 to N (over the satellite insert channel);
where N = (modulator data rate) divided by
(64 kbps).
cc = 1 to 24 (terrestrial channel number for T1
data formats).
cc = 1 to 31 (terrestrial time slot number for E1
data formats).
cc = 0 if no insert is desired for the specified
insert channel.
Notes:
1.The status response returns programming
information for 1 to N insert channels.
2.Time slot 16 (cc = 16) may not be specified
when the insert data format is specified to be
E1CAS.
3.This command is not valid when the insert
data format is specified as E1CAS and the
demodulator data rate is set to 1920.0 kbps.
ASYNC Transmit
Overhead Baud
Rate Command:
Response:
Status:
Response: >add/TOBR_nnnnn'cr''lf']
>add/TOBR_nnnnn'cr''lf']
Where: nnnnn = 110, 150, 300, 600, 1200,
2400, 4800, 9600, 19200, or 38400.
Note: TX ASYNC Overhead only.
ASYNC Receive
Overhead Baud
Rate Command:
Response:
Status:
Response: >add/ROBR_nnnnn'cr''lf']
>add/ROBR_nnnnn'cr''lf']
Where: nnnnn = 110, 150, 300, 600, 1200,
2400, 4800, 9600, 19200, or 38400.
Note: RX ASYNC Overhead only.
ASYNC Transmit
Channel
Character Length Command:
Response:
Status:
Response: >add/TCCL_n'cr''lf']
>add/TCCL_n'cr''lf']
Where: n = 5, 6, 7, or 8 (characters).
Note: TX ASYNC Overhead only.
ASYNC Receive
Channel
Character Length Command:
Response:
Status:
Response: >add/RCCL_n'cr''lf']
>add/RCCL_n'cr''lf']
Where: n = 5, 6, 7, or 8 (characters).
Note: RX ASYNC Overhead only.
