SDM-300A Satellite Modem Revision 6
Front Panel Operation MN/SDM300A.IOM
5–87
FUNCTION SELECT: UTILITY: INTERFACE: FRAMING STRUCTURE
FRAMING
STRUCTURE
Displays the currently selected framing type and structure of the data. This function is used with
the buffer program in milliseconds (ms) for plesiochronous buffer slips.
Upon entry, the framing type (T1 or E1) is displayed on Line 1. The framing structure of each
type (None or G.704) is displayed on Line 2. Press [
←] or [→] and [↑] or [↓] to select framing
structure and type. Press [ENTER] to execute the change.
FUNCTION SELECT: UTILITY: INTERFACE: FRAMING STRUCTURE:
FRAMING STRUCTURE: T1 FRAMING
T1 FRAMING
STRUCTURE: G.704
NONE or G.704
Upon entry, the framing type (T1 or E1) is displayed on Line 1. The framing structure of each
type (None or G.704) is displayed on Line 2.
Press [
←] or [→] and [↑] or [↓] to select framing structure and type. Press [ENTER] to execute
the change.
FUNCTION SELECT: UTILITY: INTERFACE: FRAMING STRUCTURE:
FRAMING STRUCTURE: E1 FRAMING
E1 FRAMING
STRUCTURE: G.704
NONE or G.704
