SDM-300A Satellite Modem Revision 6
Front Panel Operation MN/SDM300A.IOM
5–102
5. The revision emulation feature does not affect some interface changes for the direct
operation of the modem (Configuration save/recall, test mode screen in the
Utility/System, all factory setup modes, etc.).
FUNCTION SELECT: UTILITY: MODEM TYPE:MODEM OPTIONS
MODEM OPTIONS
+ + - + - - - + + + + + - - +
Status Only
Displays the installed modem options.
If the option is installed, a “+” symbol is displayed. To view the available options press
[ENTER]. Observe for the flashing cursor. Press the [
←] [→] arrows to move from one symbol
to the next. The first line will display the option. The second line will display the status:
Option Code Legend
HIGH POWER
HIGH STABILITY
ASLT
VITERBI
SEQUENTIAL
SINGLE RATE
LOW RATE VAR
FULL RATE VAR
CARD #1 PCB
CARD #2 PCB
CARD #3 PCB
8PSK 2/3
TX only
RX only
OQPSK
BURST (0 or +)
(0 or +)
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
(x or +)
(x or +)
(x or +)
(- or +)
(0 or +)
(0 or +)
(- or +)
(- or +) 0 = Not Installed, Factory Upgradable
- = Not Installed, FAST Upgradable
+ = Installed
x = Not Installed, Field Upgradable
IMPORTANT
The actual choices displayed in the sub-menus may vary according
to which FAST options have been enabled. Where a FAST option
affects a menu, this is shown in the descriptive text.
