SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–13
Interface Buffer
Size Buffer size programming is supported in two formats; bits, or milli-seconds. The selected format must be chosen
using the buffer programming command (IBP_). If the buffer is to be programmed in milli-seconds and
plesiochronous slips are required use the receive framing structure command (IRFS_) to define the proper framing
format.
Note: For Drop & Insert: Only milli-seconds format is allowed.
Interface Buffer
Size (Bit Format) Command:
Response:
Status:
Response: >add/IBS _nnnnnn'cr''lf']
>add/IBS _nnnnnn'cr''lf']
Where: nnnnnn = 32 to 262144, in 16 bit
increments.
Interface Buffer
Size (Milli-second
Format) Command:
Response:
Status:
Response: >add/IBS _nn'cr''lf']
>add/IBS _nn'cr''lf']
Where: nn = 0 to 99 (buffer size in milli-
seconds).
Note: For Drop & Insert:
1. nn = 7.5, 15, or 30 (milli-seconds) for
E1CAS format.
2. nn = 6, 12, 24, or 30 (milli-seconds) for
T1S/T1ESFS format.
3. nn = 1, 2, 4, 8, 16, or 32 (milli-seconds)
for all other D&I formats.
Interface Buffer
Center Command:
Response:
>add/IBC_'cr''lf']
Interface Buffer
Programming Command:
Response:
Status:
Response: >add/IBP_xxxx'cr''lf']
>add/IBP_xxxx'cr''lf']
Where: xxxx = BITS or MS (milli-seconds).
Note: For Drop & Insert: Only milli-seconds
format is allowed.
Interface Receive
Farming
Structure Command:
Response:
Status:
Response: >add/IRFS_ff_ssss'cr''lf']
>add/IRFS_ff_ssss'cr''lf']
Where:
ff = T1 or E1 (frame type).
ssss = NONE or G704 (framing structure).
Interface
Substitute Pattern Command:
Response:
Status:
Response: >add/ISP_xxxxxx'cr''lf']
>add/ISP_xxxxxx'cr''lf']
Where: xxxxxx = ON or OFF.
Note: Transmit 2047 Pattern.
