Table 5-3. Custom Modem Defaults (Continued)
Configuration Local AUPC
AUPC Enabled Off Target Eb/N0 0.6 dB
Nominal Power -10.0 dB Tracking Rate 0.5 dB/min
Minimum Power -30.0 dBm Local CL Action Hold
Maximum Power -5.0 dBm Remote CL Action Hold
Configuration Mux
Tributary Frequency #1 2048 kbps Tributary #1 to #7 SYNC
Tributary Frequency #2 to #7 256 kbps Tributary #8 ASYNC
Tributary Interface #1 and #8 RS422 Tributary Clock Data CLK:NRM
Data NRM
Tributary Interface #2 to #7 RS232 Aggregate DR 2305 kbps
Configuration Flex Mux
TX Chan # 1 Mode D&I Enabled RX Chan # 1 Mode D&I Enabled
TX Chan # 1 DR 64.0 kbps RX Chan # 1 DR 64.0 kbps
TX Chan # 2 Mode ADPCM Disabled RX Chan # 2 Mode ADPCM Disabled
TX Chan # 3 Mode SYNC RS232 RX Chan # 3 Mode SYNC RS232
TX Chan # 3 DR 64.0 kbps RX Chan # 3 DR 64.0 kbps
TX Chan # 3 Phase CLK: NRM DATA: NRM RX Chan # 3 Phase CLK: NRM DATA: NRM
TX Chan # 4 Mode ASYNC RS485 RX Chan # 4 Mode ASYNC RS485
TX Chan # 4 DR 9.6 kbps RX Chan # 4 DR 9.6 kbps
TX Chan # 4 Phase CLK: NRM DATA: NRM RX Chan # 4 Phase CLK: NRM DATA: NRM
Function Select Monitor
RAW BER 2.4 E-3 Sweep Frequency 0 Hz
Corrected BER 4.0 E-3 Buffer Fill 50%
Eb/N0 16.0 dB Frame Errors n.n E-e
Receive Signal -45 dB
Function Select Remote AUPC
AUPC Enable Off TX 2047 Pattern Off
B-Band Loopback Off 2047 Errors n.n E-e
