6.1.4 ASYNC/AUPC Operation
To operate in the Asynchronous/AUPC configuration, the following cards must be
installed in the modem:
• Overhead G.703/IDR/IBS/ASYNC/AUPC/D&I card (PL/5305-1)
• 50-pin D relay adapter card (PL/5509)
The ASYNC/AUPC option is a FAST feature that must be enabled using the front panel
and the Utility: Modem Type menu. Table 6-6 lists that are accessible once the
ASYNC/AUPC modem type is enabled.
Table 6-6. Asynchronous Parameter Settings
Parameter Front Panel Setting Reference Menu
Modem Type ASYNC Utility : Modem Type
TX Data/Code Rate TX-V, BPSK 1/2 or QPSK
1/2, 3/4, or 7/8 Configuration: Modulator
TX-IF Output ON Configuration: Modulator
RX Data/Code Rate RX-V, BPSK 1/2 or QPSK
1/2, 3/4, or 7/8 Configuration: Demodulator
Encoder Type Viterbi/Sequential Utility: Modulator
Decoder Type Viterbi/Sequential Utility: Demodulator
ASYNC TX Baud 110 to 38400 bit/s Configuration: Interface
ASYNC RX Baud 110 to 38400 bit/s Configuration: Interface
ASYNC TX Length 5 to 8 bits Configuration: Interface
ASYNC RX Length 5 to 8 bits Configuration: Interface
ASYNC TX Stop 1 or 2 bits Configuration: Interface
ASYNC TX Parity Even or Odd Configuration: Interface
ASYNC RX Parity Even or Odd Configuration: Interface
Local AUPC ON or OFF Configuration: Local AUPC
Nominal Power -5 to -30 dBm Configuration: Local AUPC
Minimum Power -5 to -30 dBm Configuration: Local AUPC
Maximum Power -5 to -30 dBm Configuration: Local AUPC
Tracking Rate 0.5 to 6.0 dBm/min. Configuration: Local AUPC
Remote AUPC ON or OFF Function Select: Remote AUPC
AUPC Enable ON or OFF Function Select: Remote AUPC
Baseband Loopback ON or OFF Function Select: Remote AUPC
