1.5.3 UB-54 Breakout Panel
The UB-54 breakout panel functions with the MUX option as a rack-mountable unit.
For more information, refer to the Comtech EF Data UB-54 Breakout Panel Installation and
Operation Manual.
1.6 Comtech EF Data Part Numbers
Table 1-3. Comtech EF Data Part Numbers
Options Decription of Options
Chassis CEFD F/P Duplex
KT/7999
OL/7625-1
LB/7989-1 CEFD RX Only
KT/7999
LB/7989-1
OL/7625-1
SS/300A-0020 CEFD TX Only
KT/7999
LB/7989-1
OL/7625-1
SS/300A-0021
Primary Input Power 90-264 VAC
KT/8000-1 -48 VDC
KT/8000-2
Baseboard Configuration 75 Ω, -5 dB Out
PL/6093-1
75
Ω, +5 dB Out
PL/6093-2
50 Ω, -5 dB Out
PL/6093-3
50
Ω, +5 dB Out
PL/6093-4
75 Ω, -5 dB Out
H/S 10 -7
PL/6093-5
75
Ω, +5 dB Out
H/S 10 -7
PL/6093-6
50 Ω, -5 dB Out
H/S 10 -7
PL/6093-7
50
Ω, +5 dB Out
H/S 10 -7
PL/6093-8
Interface Board
25-Pin
PL/5727-1
37-Pin
PL/6031-1 Overhead – 50P
PL/5305-2
PL/5309-2
8-Channel Mux
PL/5985
PL/6029-1
50-Pin Interface
PL/6167-1
V.35 34-Pin
PL/6032-01
Flex Mux
PL/6450-1
PL/6451-1
G.703/ASYNC
W/Overhead
PL/5305-2
PL/7838-1
Reed-Solomon (R-S)
Board TX R-S
PL/6284 RX R-S
PL/6285
Duplex Reed-Solomon
Module TX/RX
PL/9658-1
Turbo Board PL/9394-1
AC Power Cord Standard
CA/17725
IEC-320
CA/90025-5ft European/French
CA/17850
United Kingdom
CA/PWR83221 Australian
WI/865516035-AUS
