SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–58
(Note 10)
(Note 8)
(Note 11)
(Note 11)
(Note 11)
(Note 8)
(Note 12)
(Note 8)
(Note 8)
(Note 13)
(Note 13)
(Note 13)
(Note 8)
(Note 14)
125
126
127
128
129
130
131
132
133
134
135
136
137
138
TX Flex Mux Channel #3 Data Phase
(ref. "TCDP_3" command).
TX Flex Mux Channel #4 Enable
(ref. "TCEN_4" command).
TX Flex Mux Channel #4 Data Rate
(ref. "TCDR_4" command).
TX Flex Mux Channel #4 Clock Phase
(ref. "TCCP_4" command).
TX Flex Mux Channel #4 Data Phase
(ref. "TCDP_4" command).
RX Flex Mux Channel #1 Enable
(ref. "RCEN_1" command).
RX Flex Mux Channel #1 Data Rate
(ref. "RCDR_1" command).
RX Flex Mux Channel #2 Enable
(ref. "RCEN_2" command).
RX Flex Mux Channel #3 Enable
(ref. "RCEN_3" command).
RX Flex Mux Channel #3 Data Rate
(ref. "RCDR_3" command).
RX Flex Mux Channel #3 Clock Phase
(ref. "RCCP_3" command).
RX Flex Mux Channel #3 Data Phase
(ref. "RCDP_3" command).
RX Flex Mux Channel #4 Enable
(ref. "RCEN_4" command).
RX Flex Mux Channel #4 Data Rate
(ref. "RCDR_4" command). p125 = n, where 'n' is '0' (Normal) or '1' (Invert).
p126 = n, where 'n' is '0' (Disabled), '1' (Sync RS232), '2'
(Async RS232), '3' (Async RS485), or '4' (AUPC operation).
p127 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p128 = n, where 'n' is '0' (Normal) or '1' (Invert).
p129 = n, where 'n' is '0' (Normal) or '1' (Invert).
p130 = n, where 'n' is '0' (Disabled), '1' (D&I), or '2' (T1/E1
operation).
p131 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p132 = n, where 'n' is '0' (Disabled), '1' (Enabled).
p133 = n, where 'n' is '0' (Disabled), '1' (Sync RS422), '2'
(Async RS422), '3' (Sync RS232), '4' (Async RS232), or '5'
(AUPC operation).
p134 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
p135 = n, where 'n' is '0' (Normal) or '1' (Invert).
p136 = n, where 'n' is '0' (Normal) or '1' (Invert).
p137 = n, where 'n' is '0' (Disabled), '1' (Sync RS232), '2'
(Async RS232), '3' (Async RS485), or '4' (AUPC operation).
p138 = nnnn.n, where 'nnnn.n' is the data rate in Kbps.
