SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–32
A.13 Demodulator Configuration Status
Demodulator
Config. Status Command:
Response:
>add/DCS_’cr’
DF_nnn.nnnnnnn’cr’
DR_nnnn_mmmm.mmm’cr’
ADRA_nnnn_mmmm.mmm’cr’
ADRB_nnnn_mmmm.mmm’cr’
ADRC_nnnn_mmmm.mmm’cr’
ADRD_nnnn_mmmm.mmm’cr’
ADRV_nnnn_mmmm.mmm’cr’
DE_xxx’cr’
DDEC_xxx’cr’
RFL_xxx’cr’
IFL_xxx’cr’
SCF_snnnnn’cr’
SWR_nnnnn’cr’
SR_xxx’cr’
BERT_xxxx’cr’
DT_xxxx’cr’
DDT_xxx’cr’
DSR_xxx’cr’
RSDE_xxx’cr’
RDA_xxx’cr’
RRSI_xx’cr’
R310_xxx’cr’’lf’]
Demodulator Frequency
Demodulator Rate
Preset ‘A’ Assignment
Preset ‘B’ Assignment
Preset ‘C’ Assignment
Preset ‘D’ Assignment
Preset ‘V’ Assignment
Descrambler Enable
Differential Decoder
RF Loopback
IF Loopback
Sweep Center Frequency
Sweep Width Range
Sweep Reacquisition
BER Threshold
Demodulator Type
Demodulator Decoder Type
Demodulator Spectrum Rotation
Reed-Solomon Decoder
Receive BPSK Data Ordering
RX Reed-Solomon Interleave Value
RX 8PSK 2/3 IESS-310 Operation
The demodulator configuration status command causes a block
of data to be returned by the addressed modem. The block of
data reflects the current configuration of the demod. Additional
configuration status of new options and features will always be
appended to the end.
