Z80 Instruction Set UM008007-0715
98
Z80 CPU
User Manual
LD IX, nn
Operation
IX ← nn
Op Code
LD
Operands
IX, nn
Description
The n integer is loaded to Index Register IX. The first n operand after the op code is the
low-order byte.
Condition Bits Affected
None.
Example
Upon the execution of an LD IX, 45A2h instruction, the index register contains integer
45A2h .
M Cycles T States 4 MHz E.T.
4 14 (4, 4, 3, 3) 3.50
1 1 1 0 1 1 0 1 DD
0 0 0 0 1 0 1 0 21
n
n
