Appendix
Operating Manual PNOZmulti 2 Communication Interfaces
1002971­EN­02 101
8 Appendix
8.1 Tables
There are a total of 11 tables, with the following contents:
Table 20: Process data, base unit
Table 21: Process data, right­hand expansion modules
Table 22 Process data, left­hand expansion modules
Table 23: Process data, fieldbus module / communication module
Table 70: Diagnostic words
Table 71: Enable elements
Table 80: Project information
Table 90: Device data, base unit
Table 91: Device data, right­hand expansion modules
Table 92 Device data, left­hand expansion modules
Table 93: Device data, fieldbus module / communication module
8.1.1 Table 20 ­ Process data, base unit
Table 20 consists of 3 segments, each of which has 13 Bytes. It contains the base unit's
process data with
} The state of the inputs and outputs
} The status of the system LED for
– supply voltage,
– diagnostics
} The state of the inputs and outputs, which is displayed on the device.
Segment Byte Content
State of inputs i0 … i31
0
0 Bit 7 … Bit 0
i7 i6 i5 i4 i3 i2 i1 i0
1 i15 i14 i13 i12 i11 i10 i9 i8
2 i23 i22 i21 i20 i19 i18 i17 i16
3 i31 i30 i29 i28 i27 i26 i25 i24
State of outputs o0 … o31
0
4 o7 o6 o5 o4 o3 o2 o1 o0
5 o15 o14 o13 o12 o11 o10 o9 o8
6 o23 o22 o21 o20 o19 o18 o17 o16
7 o31 o30 o29 o28 o27 o26 o25 o24
