64
Programming Reference
VERSAJET
A → D
↓
printing area
↑
B ← C
ESC T
[Name] Select print direction in page mode
[Format] ASCII ESC T n
Hex 1B 54 n
Decimal 27 84 n
[Range] 0 ≤ n ≤ 3, 48 ≤ n ≤ 51
[Default] n = 0
[Description] In page mode, selects the print direction and starting position, using n as follows:
n
Printing
Direction
Starting Position
0, 48 Left to right Upper left (A in the figure)
1, 49 Bottom to top Lower left (B in the figure)
2, 50 Right to left Lower right (C in the the figure)
3, 51 Top to bottom Upper right (D in the figure)
[Notes]
The print direction set by this command is effective only in page mode.
