134
Programming Reference
VERSAJET
GS ( k Code49
[Format] ASCII GS ( k pL pH cn fn n
Hex 1D 28 6B 03 00 39 44 n
Decimal 29 40 107 3 00 57 68 n
[Range] (pL + pH x 256) = 3 (pL = 3, pH =0)
cn = 57, fn = 68
1≤ n ≤ 255
[Default] n = 16
[Description] Specify the height of one row.
[Notes]
Settings of this function affect the processing of Functions 981.
Settings of this function are effective until ESC @ is executed, the printer is reset, or the
power is turned off.
The module height influences the recognition rate of the symbol.
For Code49, the minimum recommended symbol height is 8X, where X is the width of
narrow element (reference ).
The setting unit is 0.1 mm.
