101
Programming Reference
VERSAJET
GS ( k PDF417
[Format] ASCII GS ( k pL pH cn fn m n
Hex 1D 28 6B 04 00 30 45 m n
Decimal 29 40 107 04 00 48 69 m n
[Range] (pL + pH x 256) = 4 (pL = 4, pH =0)
cn = 48, fn = 69
m = 48
48 ≤ n ≤56 [m = 48]
[Default] m = 48 , n = 48
[Description]
Specifies the error correction level of PDF417. The error correction level is specified by
“level” when m = 48.
[Notes]
Settings of this function affect the processing of Functions 081.
Error correction level is specified by either “level”.
Error correction level specified by “level” (m = 48) is as follows. The number of the error
correction code word is fixed regardless of the number of code words in the data area.
n Function Number of error correction code word
48 Error correction level 0 2
49 Error correction level 1 4
50 Error correction level 2 8
51 Error correction level 3 16
52 Error correction level 4 32
53 Error correction level 5 64
54 Error correction level 6 128
55 Error correction level 7 256
56 Error correction level 8 512
