5-14 Broadmore 1750 - Release 4.6
Module and Fan Installation
Fan Tray Installation Procedure
Fan Tray Installation Procedure
Tools ... 5-15
Remove Front Chassis Cover ... 5-15
Fan Tray Installation ... 5-15
Replace Chassis Cover ... 5-16
The fan tray is normally shipped installed in the front of the chassis below the modules,
as shown below. If it is not installed, follow the procedure below to install it.
Rear Cover
Midplane*
Chassis Cover*
Network
Interface
Module
Input/
Output
Module
Front
Fan
Cover
Tray
Rack Mounting
Brackets
*Not User Removable
