Page 77
Broadmore 1750 - Release 4.6
4-5
Chassis Installation and Grounding
Mounting Brackets
Mounting Brackets
The Broadmore 1750 chassis 17.5" high and is shipped from the factory assembled for
front-mounting in a standard 19" EIA or relay rack.
WARNING!
T
HE
B
ROADMORE
1750
MOUNTING
BRACKETS
SHALL
BE
CONNECTED
TO
THE
CHASSIS
USING
ONLY
THE
SCREWS
PROVIDED
FOR
INITIAL
BRACKET
INSTALLATION
. T
HE
INSTALLER
SHALL
BE
RESPONSI
-
BLE
FOR
PROVIDING
A
STABLE
RACK
THAT
SUPPORTS
THE
WEIGHT
OF
THE
B
ROADMORE
1750
AS
INSTALLED
.
The mounting brackets can be moved to accommodate 23" racks and other mounting
positions. To install the chassis in 23" racks, remove the mounting brackets, rotate them
90 degrees, and reattach them to the chassis.
If desired, alternate mounting holes are provided for moving the mounting brackets
forward or backward for other mounting configurations.
The six possible rack-mounting bracket configurations are shown below.
19
23
15.31
9.31
6.00
7.66
7.66
FRONT
REAR
TOP
FRONT-MOUNT
MID-MOUNT
Mounting
Brackets
