7-22 Broadmore 1750 - Release 4.6
Configuration
General Properties
Bandwidth Meter
The Bandwidth meter allows you to track the amount of bandwidth in use. Follow
the sequence below and make the appropriate choice from the screen shown.
NOTE: The Bandwidth meter uses the clock rate of the HSSI NIM as the
bus rate. If the HSSI NIM is set for received timing, the bandwidth meter
will not be using the correct bus rate because the clock is supplied by the
HSSI at the other end. Be sure to check how the HSSI's clock is set before
using the Bandwidth meter.
Select System Management
↵
Select Configuration
↵
Select System Services
↵
Select General Properties
↵
Select Bandwidth Meter
↵
