Broadmore 1750 - Release 4.6
7-69
Configuration
VP Reservation
Item
Comments
Connection Name
Press the space bar to select Connection Name and type a descriptive
identifier (For example, test port 2).
Local Slot
The Local Slot is the chassis slot.
VP
The range is 0 to one less than the value set for maximum VPs (see
for valid values). If the Max VP/VC value is set to
2/65536, the VP number must be set to 0; a value of 1 is invalid.
NOTE: A maximum of 40 VPs can be defined for reservation.
VC Start
The default range is 32 to the value set for maximum VCs (see
for valid values). VC numbers can start at 1 if the VP
is not set to 0.
VC End
The default range is 32 to the value set for maximum VCs (see
for valid values). VC numbers can start at 1 if the VP
is not set to 0.
