Caution – Carrier Access Broadmore 1750 User Manual
Page 144
7-30
Broadmore 1750 - Release 4.6
Configuration
SAM Redundancy
Slot M has the highest priority, followed in order by slot J, slot F, and slot C. The P-
SAM provides redundancy according to the following:
Only a single W-SAM is protected
In the case of more than one request for the P-SAM, only the highest priority W-
SAM is protected
If the P-SAM is protecting a W-SAM, then a request from a lower priority W-
SAM is ignored until the higher priority clears
If the P-SAM is protecting a W-SAM, then a request from a higher priority W-
SAM is honored (and the protection for the first-protected W-SAM is lost)
P-SAM is invoked for removal of a W-SAM, or by user command
Redundancy is not reverting. After correction of a W-SAM problem, switch back
manually
Wait at least 15 seconds between removal and insertion of SAMs to ensure
system stabilization.
CAUTION!
F
AILURE
TO
WAIT
15
SECONDS
BETWEEN
EVENTS
MAY
LEAD
TO
A
CONDITION
WHERE
A
W-SAM
DOES
NOT
RETURN
TO
FULL
OPERATION
. I
N
THIS
CASE
,
FOLLOW
THE
STEPS
BELOW
TO
CORRECT
THE
PROBLEM
.
Perform the following steps to enable SAM Protection:
1. Go to APS Parms and select Mode Enabled.
Select Maintenance/Diags
↵
Select Redundancy
↵
Select SAM
↵
Select APS Parms
↵
Change Mode Enabled
↵
