Broadmore 1750 - Release 4.6 7-59
Configuration
Unstructured E3-3 SAM
Table 7-14: Unstructured E3-3 SAM Diagnostics Configuration
Network RDI Auto
X-bits 1
X-bits 0 A Remote Defect Indication (RDI) is LOS or LOF detected on the attached
equipment of the network side. Auto sets the RDI to automatically reflect
whether or not an error is present. 1 sets an error to occur whether one is
present or not. 0 indicates no errors even if one is present.
Service RDI Auto
X-bits 1
X-bits 0 A Remote Defect Indication (RDI) is LOS or LOF detected on the attached
equipment of the network side. Auto sets the RDI to automatically reflect
whether or not an error is present. 1 sets an error to occur whether one is
present or not. 0 indicates no errors even if one is present.
Item Options Comment
Network BERT Test Activate/Deactivate BERT test can only be performed when the
port is configured for C-bit parity framing.
Causes the port to generate a 2e
23
pseudo-
random test pattern to the ATM network.
Service BERT Test Activate/Deactivate Same as network BERT test except it goes to
the service equipment. These tests can be
monitored from CAMMI following the
selection sequence: system management
→
monitor activity
→slot statistics→ E3 SAM →
Port # → Port Counters
Network AIS Activate/Deactivate Sends Alarm Indication Signal to the network
when activated.
Service AIS Activate/Deactivate Sends Alarm Indication Signal to the
connected local service equipment when
activated.
Loopback Normal
Local
Remote
Normal is no loopback.
Local sets a service side loopback (E3) on the
port.
Remote sets a network side loopback (ATM)
on the port.
See diagram “Loopback Options” on page 5-20
Item Options Comments
