Broadmore 1750 - Release 4.6
8-17
Maintenance and Troubleshooting
CPU Sync
CPU Sync
Follow the sequence below to view the CPU synchronization status between redundant
CPUs. This screen shows the progress of a normal CPU Sync and will refresh every
few seconds. The messages usually do not indicate any problem but can be useful if
troubleshooting is required. When a CPU sync is in progress, the screen will list the
number of files remaining and the current file name being synchronized. The files listed
on the left side are those that would inhibit a controlled switchover.
NOTE:
See also “Synchronizing CPU” on page
.
Select System Management
↵
Select Monitor Activity
↵
Select CPU Sync
↵
