Broadmore 1750 - Release 4.6 7-29
Configuration
SAM Redundancy
SAM Redundancy
In the Broadmore 1750, installing an Unstructured DS3 SAM in slot P provides 1:N
SAM redundancy. A special Protection IOM with no user interface is used, since input/
output will continue to be provided via the cables attached to the slot of the failed SAM.
The Unstructured DS3 in slot P is called the protection SAM, or P-SAM. The working
SAMs, called W-SAMs, are installed in slot C, slot F, slot J, and slot M.
Follow the sequence below to enable and configure SAM redundancy.
Select Maintenance/Diags
↵
Select Redundancy
↵
Select SAM
↵
Select APS Parms
↵
