Broadmore 1750 - Release 4.6
7-19
Configuration
UNI Version
UNI Version
The signaling options are UNI 3.1, UNI 4.0, Auto, and Off. Follow the sequence below
and make the appropriate choice from the screen shown.
NOTE:
You must select the UNI Version before configuring any SVCs.
If there are active SVCs, the UNI Version will not appear in the menu until
you release all the SVCs. This is done to prevent interrupting service on
those circuits.
The UNI Version selection screen appears as shown below with the current selection
highlighted.
CAUTION!
UNI V
ERSION
SHOULD
BE
O
FF
WHENEVER
THE
NIM
S
ARE
NOT
CONNECTED
TO
AN
ATM
SWITCH
INTERFACE
CONFIGURED
FOR
UNI
SUPPORT
.
Select System Management
↵
Select Configuration
↵
Select System Services
↵
Select UNI Version
↵
