8-44 Broadmore 1750 - Release 4.6
Maintenance and Troubleshooting
Summary of Front Panel LEDs
Summary of Front Panel LEDs
The following table provides descriptions of the front panel LEDs for the Broadmore
1750.
Module LED Display LED Color Definition
APM Major Alarm Red Major fault for 2.5 seconds
None No major alarm
Minor Alarm Amber Minor alarm for 2.5 seconds
Not Lit No minor alarm
*Over Temp Red * Not supported at this time.
Not Lit
Power Green -48 volts power is present
Not Lit No power present
Power Fail A/B Red
Not Lit
NIM Fault Red Major alarm detected for 2.5 seconds
Amber Minor alarm detected for 2.5 seconds
Green Normal, no fault condition
On-Line Red-flashing NIM failed POST, not ready
Amber NIM passed POST and in standby
Green NIM is online, normal
LOS Red Loss of Signal
Green Acceptable optical receive power for 10 seconds
SAM Fault Red Major alarm detected for 2.5 seconds
Amber Minor alarm detected for 2.5 seconds
Green Normal, no fault condition
Not Lit Out of service
On-line Red SAM failed POST, not ready
Amber offline or standby
Green Normal, no fault condition
Alarm Red Major
