7-8 Broadmore 1750 - Release 4.6
Configuration
System Services Configuration
System Services Configuration
Configure System Services to communicate with the ATM switch and set up
parameters for Broadmore 1750 control. The data entry screens are accessed as shown.
CAM Name
Each Broadmore 1750 can be named locally. A short (10-character) name and a long
(64-character) name are available. These two names are independent as chosen by the
operator. The long name appears at the top of CAMMI screens to provide on-screen
identification. The short name appears as a shell prompt. The default long name is a
null field and the default short name is Broadmore>.
From CAMMI, follow the sequence below to enter names.
Select System Management
↵
Select Configuration
↵
Select System Services
↵
Configure each item as explained below
Select System Management
↵
Select Configure
↵
Select System Services
↵
Select CAM Name
↵
Enter the desired long and short names
↵
