Broadmore 1750 - Release 4.6 8-29
Maintenance and Troubleshooting
Flowchart
Figure 8-8: SAM Minor Alarm Troubleshooting Flowchart
From 6
Use loopbacks to
isolate alarm condition
Alarm Internal?
Contact distant end -
have them commence
troubleshooting
Alarm Clears ?
6 A
Review Alarm Summary
and System Log- call
Customer Service with
pertinent information
6 B
Return to 6
Check most likely
causes as necessary
-Port configuration
-reseat module
-cable connections
-replace SAM
Alarm clears ?
Define actions to
correct most probable
causes
Alarm clears ?
No
Yes
No
Yes Yes
No
Yes
No
6 B
