Broadmore 1750 - Release 4.6
5-7
Module and Fan Installation
Module Locations
CAUTION!
W
HEN
USING
REDUNDANT
OPTICAL
NIM
S
,
BOTH
NIM
S
MUST
BE
IDENTICAL
.
NOTE:
The Broadmore 1750 chassis will only support five Structured
DS3 modules with the standard 2-fan cooling tray. For applications needing
more than five Structured DS3 modules, a 3-fan cooling tray is required
(contact factory for details).
Module Type
Description
Available Slot(s)
CPU
CPU
Q
Redundant CPU
R
NIM
OC-12c/STM-4c B
Redundant NIM (OC-12c)
A
SAM
Unstructured DS3
C, F, J, M
Unstructured E3
C, F, J, M
Protection Unstructured DS3/E3
P
Structured DS3 (up to 10 modules)
C-N
Protection Structured DS3
P
