Broadmore 1750 - Release 4.6
2-11
Planning
and
Ordering Guide
ATM Bandwidth per Cell Bus
ATM Bandwidth per Cell Bus
Depending on the SAMs being used, a Broadmore 1750 chassis with an OC-12c NIM
can multiplex data onto all four ATM cell buses, providing a maximum ATM
bandwidth of up to 599.04 Mbps.
The maximum ATM bandwidth for each cell bus is shown below.
Cell Bus
Service Slots
ATM Bandwidth
Available to SAMs
A
C thru N (used by SAMs)
Q, R (used by CPUs for AAL5
management traffic)
< 129.48 Mbps
C
C, D, E
< 155.52 Mbps
D
F, G, H
< 155.52 Mbps
E
J, K, L
< 155.52 Mbps
Total
All service slots
< 599.04 Mbps
