Broadmore 1750 - Release 4.6 12-17
SNMP Configuration
Views
Once this menu option is chosen, a list of existing groups will be displayed. To choose
the required action on groups, highlight any of the existing entries and press the Enter
key. The following shows the New View SubTrees Entry screen.
The managed objects in Broadmore are organized in a tree structure, known as a MIB
tree, based on the OID (Object Identifier) of each object. A view defines a particular
subtree in this MIB tree. For example, one view could be defined to be over the MIB
subtree represented by the OID 1.3.6 while another could be over the subtree
represented by OID 1.3.6.1. Of these two views, the latter is more restrictive as it has
fewer managed objects under it. A view could also be defined to be one specific OID
in the entire MIB tree of managed objects. The following shows the New View
SubTrees view.
The following table describes the selections
Item Options Comments
Name string Unique value for View Name, 1 to 30 characters.
Default is “iso” standard.
Subtree OID string Unique value for Object Identifier, such as “1.3.6”.
