C-More Controller for Benchmark, Innovation & KC
USER MANUAL
04/22/14 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, New York 10913 Page 141 of 162
OMM-0032_0E Phone: 800-526-0288 GF-112
40051 Write Control
Values to BST The BAS must write a 1 to this location for the first 4 values to
be copied across the SSD device, to the BST side. In normal
operation update the 4 registers 40200 through 40203 fairly
regularly. Once all four have been written, write a one to
40051. This is done to insure that all control values are copied
to the BST side of the SSD as a block.
40050 Write Op Values
to BAS BST Master writes to this address to copy operational
parameters to the BAS side of the SSD. The BAS should
never read or write this address.
Reading Operational Data
The registers used to read operational data are 30100 through 30108 and 40054.
BAS
Register Use Description
30100
BST This will typically always read as 2.
30101 BST setpoint This is the temperature to which each boiler in the system will
control outlet temp. This values is not used in BST Mode.
30102 BST setback
setpoint This is the temperature to which each boiler in the system will
control outlet temp to during the night setback period (if night
setback is enabled).
30103 BST setback start The time the setback period starts. This is expressed in
minutes since midnight. So for example 360 would correspond
to 6am.
30104 BST setback end The time the setback period ends. This is expressed in
minutes since midnight. If setback start and setback end are
the same value, there is no setback period.
30105 Auto Master Zero “0” if the master unit is fixed, one “1” if it can
automatically failover to another unit after a fault.
30106 Average Outlet
Temperature This is an average outlet temperature of all ignited boilers in
the system. Note! This item is for Water Heater units only.
30107 Units Enabled This is the number of boilers in the system that can be lit off.
30108 Units Faulted This is the number of boilers in the system that are faulted.
30109 Master Address The Master Address is the comm address of the Master unit.
30110 BST Header
Temp The BST Header Temp is the BST Header Temperature
reading.
30111 BST Outdoor
Temp The BST Outdoor Temp is the Outdoor Temperature reading if
an outdoor temperature sensor is installed).
30112 BST Fire Rate The BST Fire Rate is the Fire Rate command sent to all
ignited boilers.
30113 Units Ignited This is the number of ignited units.
30114 BST Active
Setpoint The actual setpoint the BST Master is working towards,
depending on the BST Setpoint Mode.
30115 BST Next On VP The Fire Rate (Valve Position) above which the BST master
will light off another boiler if available.
