Benchmark 1500DF - 2000DF Boilers

CHAPTER 7 – MAINTENANCE

OMM-0098_0A

AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913

Page 97 of 196

GF-144

Ph.: 800-526-0288

04/01/2014

Burner Assembly Inspection and Maintenance Procedures (Cont.)

11.

Remove the eight (8) 3/8-16 nuts, using a 9/16” wrench, attaching the blower plenum to

the burner beneath (see Figure 7-4a & 7-4b).

12.

Remove the blower plenum from between the blower and the burner and set aside for

later reassembly. O2 sensor and flame observation port remain assembled to the plenum

flange.

NOTE

The burner assembly is heavy, weighing approximately 65 lbs.

13.

Remove the burner by pulling straight up.

14.

Remove and replace the burner gasket(s) (see Figure 7-5).

IMPORTANT!

ALL THREE gaskets provided for maintenance MUST be installed

during this procedure, as shown in Figure 7-5, even if there is only

one existing gasket being replaced. Note that the LOWER

RELEASE GASKET has tabs, which the others do not.

NOTE

During reassembly, apply a light coating of high-temperature, anti-

seize lubricant to the threads of the igniter-injector and grounding

screw. Also, ensure that the igniter-injector is properly positioned

as indicated in Figure 7-3. Torque the igniter-injector to 170 - 180

in-lbs.

15.

Beginning with the burner assembly, reinstall all the components in the reverse order that

they were removed. When reinstalling the blower plenum (removed in step 11), tighten

the 3/8-16 nuts using a typical torque pattern (for example, loosely tighten one nut, then

loosely tighten a second nut on the opposite side, a third at 90 degrees to the first two,

and a fourth opposite the third, and then repeat this pattern with the remaining four nuts.

Repeat the entire pattern a second time to partially tighten all eight nuts, and then repeat

a third time until all eight nuts are fully torqued to 22 ft. lbs).

16.

Ensure that the igniter-injector and flame detector cutouts in the burner plate are properly

aligned with the heat exchanger top flange.
