Benchmark 1500DF - 2000DF Boilers
CHAPTER 3 – OPERATION
Page 36 of 196 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0098_0A
04/01/2014 Ph.: 800-526-0288 GF-144
Figure 3-1: Control Panel Front View
*NOTE
If there is a requirement to use the RS232 port (Item 4) on the C-
More controller front panel, contact AERCO to purchase the
RS232 Adaptor Cable (P/N 124675), which is designed for this
purpose. This cable features a DB9 connector for connection to
older computers with serial ports or can be used with a Serial-to-
USB adaptor for use in modern computer USB ports.
3
1
8
9
10
11
7
6
5
*4
12
2
