LEVEL Type Input
Remote Site
Sensor In 1 :
Sensor In 2 :
Sensor In 3:
Alarm Call:
View Point Change;
Communication :
Disconnection Timer:
Control Site
Alarm Image Display:
t>1 s ------------------------------------------ V
V
I
y.
I
t
^ r
' I ' I
. -X- - -I - ^ -
' I ' 1
Esta^hed
#
---------------------- iff ---------------------------
------------------------- if — ^------------------------ )|< —
Disconnected Established
--------------------- a —— k —
-------------------
Start
~fl ---------- --------------------------
End
Sensor 1 Sensor 2 Sensor 3
Image Image Image
Sens 1
About the Right of Control
There are some limitations on the right of control when more than one WJ-NT204 receiver (Control site) access to one transmit­
ter (F7emote site).
The earliest Control site who has connected with the transmitter first can have the following right of control, while the other sites
are limiteo’.
Camera control for the Remote site
Serial port control for the Remote site
Parallel port control for the Remote site
Audio transmission to the Remote site (bi-directional audio communication)
The other sites can operate the following functions.
Receiving the transmitted audio and image
Set TRANS CONTROL to OFF for the site you do not want to give the right of control in the 100 CONFIGURATION menu. The
site may establish only bi-directional audio communication except camera control, serial or parallel control even though it is set
to OFF for TRANS CONTROL.
The right of control is not limited when the Control site employs a PC, not a WJ-NT204 receiver.
147
