SPEGIFICATIONSj
General
Power supply:
Power consumption:
Weight:
Dimensions:
Working temperature range:
Working humidity range:
Applicable line:
Communication protocols:
Video input:
Video output
Image compression system:
Audio input
Audio output:
Audio compression system:
Control System
Data port:
Parallel port:
Sensor input/Trigger output:
Host port:
120 V A C . 60 Hz
13 W max.
4 kg (8.8 lbs.)
420 mm (W) x 44 mm (H) x 350 mm (D) (no rubber feet and bosses included)
16-9/16” (W)
X
1-3/4” (H) x 13-3/4” (D)
Specified temperature: -t-5 ‘C - -t-40 "C (41 °F -104 T)
Operating temperature: -10 ‘C ~ +60 °C (14 T -140 T)
95 % maximum
10BASE-T/100BASE-TX, RJ45
TCP, IP, UDP, ICMP. FTP, HTTP, H.323
Video input 1 -4 and AUX, NTSC composite /1 V[p-p]/75Q, BNC
Video output 1 - 4, NTSC composite /1 V[p-p]/75ii, BNC
Monitor/Spot output, NTSC composite /1 V[p-p]/75ii, BNC
H.261, maximum communication rate 1 Mbps
(0/16/32/64/128/256/384/512/768/1024 kbps manually)
elements GIF: 352 x 288 / 640x480 (Image Size) max. 30 fps
JPEG, maximum 15 fps, GIF: 352 x 288, VGA: 640 x 480
Audio input x1, -10 dB 47 kil, RCA pin jack
Audio output x1, -10 dB 300 Q, RCA pin jack:
G,7f 1-P/G711-A, audio band 3.4kHz, or no sound
RS-232C (D-sub 9 pin male)/ 4-wire RS-485 (RJ-11 connector),
baud rate = 4 800 bps/ 9 600/19200 bps,
data length - 7-bit/8-bit,
stop = l-bit/2-bit, parity = NONE/ODD/EVEN
Note) The rear DIP switch specifies RS-232C or RS-485.
D-Sub 25-pin female, Input x8 (make-contact).
Output x8 (open collector output)
Forced (line) disconnection input x1 (make-contact)
Clock adjust signal input x1 (make-contact)
Mid-communication output x1 (open collector output)
Parallel data strobe output x1 (open collector output), +12 V output (50 mA max.)
D-Sub 25-pin female, sensor input x8 (make-contact)
Trigger output x8 (open collector output)
RS-232C (D-Sub 9-pin male) or 4-wire RS-485 (RJ-11 connector),
rate = 4 800/9 600/19 200 bps, data length = 8-bit (fixed),
stop = 1-bit (fixed), parity = NONE
Note) The front DIP switch specifies RS-232C or RS-485.
Operation System
Remote control connector: Rear: RJ-11 modular port
Host port, data port RS-485 terminating SW: ON/OFF (Set with dip switches on the rear)
Data port RS485 line changeover SW:
Straight/crossover (The rear DIP switch specifies the wiring.)
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.
