A D V A N C E D M A K E R U N F E A T U R E S
MakeRun Options
Version 2
WinPEP 7 User Guide
6-23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAKERUN OPTIONS
Selecting the MakeRun options from the Tools menu expands new menu selections.
They are shown below in the order that they appear on the menu.
M
AKE
R
UN
C
ONFIGURATION
Select Tools
!
MakeRun Options
!
MakeRun Configuration to open the MakeRun
Configuration dialog box. You can also click the MakeRun Configuration
button
. Refer to page 6-2 and page 6-4 for more information.
PID C
OEFFICIENTS
PID Coefficients are used to control the responsiveness of both the eddy current
brake and the proportional air brake. You can manually adjust the coefficients,
however, Dynojet recommends using the default values.
Select Tools
!
MakeRun Options
!
PID Coefficients
Figure 6-21: PID Coefficients
