G E T T I N G S T A R T E D W I T H W I N P E P 7
The WinPEP 7 Menu Bar
Version 2
WinPEP 7 User Guide
3-19
• Magnifier Box — magnifies a small area of the graph and displays it in a box.
• Display Negative — When Display Negative is toggled on, all data is
displayed. When off, the data is cut off below zero and only positive data will
be displayed.
• Display — determines what will be displayed on the graph. When printing the
graph, note that the Conditions will always be printed.
• Correction Factor — lets you select the correction factor applied to the data.
• Smoothing — lets you select the level of
to be applied to the data.
• Properties — opens the Graph Options dialog box where you can customize
the graph properties. Refer to page 7-6 for more information.
System Information—Displays information about the computer system.
Drum Information—Displays information about the dynamometer drum(s).
Environment Options—opens the Environment Options dialog box where you can
customize the general WinPEP 7 settings and choose your default units.
• General Tab — lets you change your language, save your current settings,
choose your toolbar size, and choose your user level. Refer to page 2-14 for
more information on user levels.
Show Complete Channel List On Graph — lets you choose to view only the
common channels or all channels. Primarily only applies to 4x4 runs. This
option is applied as runs are added to the graph, any runs already shown on
the graph will not be affected.
Use Advanced RPM Filtering — smooths out RPM signals with minor noise
problems in them. This option is applied as runs are added to the graph, any
runs already shown on the graph will not be affected.
• Default Units Tab — lets you choose a predefined unit setting or you can pick
individual units to suit your specific needs.
D
ISPLAY
M
ENU
Toolbars—lets you select which toolbars will be displayed.
Graph Screen—lets you navigate to the Graph screen.
MakeRun Screen—lets you navigate to the MakeRun screen.
