set region bounds Chapter 5. Tcl Command Reference
[-batch] Optional Postpone application of this
constraint until apply placement
is called (this avoids frequent GUI
updates). This option is only
relevant if you manually apply
placement constraints after the
design has been prepared.
set property
set property < propName > < propValue > < objects > [-quiet]
This command is used to set properties on objects in the DB.
Argument Required/Optional Description
< propName > Required The required
argument specifies property
name to set on the objects passed
in.
< propValue > Required The required
argument specifies property
value to set on the objects passed
in.
< objects > Required The required
argument specifies a list of
objects to set the property for.
Objects must be prepended with
object type prefixes (see ”find”
command).
[-quiet] Optional The optional -quiet option allows
you to disable printing of info
messages
set region bounds
set region bounds < region > < bounds > [-snap to clock regions]
This command updates a placement regions bounding box of tiles.
Argument Required/Optional Description
< region > Required Name of the region
< bounds > Required List of bounding box
coordinates x1 y1 x2 y2. x1 and
y1 are the upper left corner of
the box. x2 and y2 are the lower
right corner of the box.
[-snap to clock regions] Optional Snap the bounding box to clock
region boundaries
369 http://www.achronix.com UG001 Rev. 5.0 - 5th December 2012
