Editors Chapter 3. Concepts
Overview Page Options
Option Description
Standard Specifies the transmission standard to be used. (1)
Number of
Lanes
Sets the number of lanes to be used.
Tx Data Rate
(Gbps)
Desired transmit-side data rate.
Rx Data Rate
(Gbps)
Sets the receive-side data rate.
Ref Clock
(MHz)
Sets the reference clock.
Rx Termination
(ohms)
Rx Lane calibration impedance setting
Tx Termination
(ohms)
Tx Lane calibration impedance setting
Data Width Data width to the SerDes.
Operating
Modes
Defines whether transmit function, receive function, or both are enabled.
Enable Channel
Bonding
Enables channel bonding and deskew control between lanes.
Placement
Chip Edge Selects whether the SerDes interface is placed along the North or South edge of the
chip.
SerDes Lanes Which lanes the serdes interface is placed on.
Notes:
(1) Selecting the standard sets the default values for other options on this and other pages in the view. Some
options may not be applicable for the selected standard.
See also: Serdes Configuration Editor , Creating an IP Configuration .
