Editors
Chapter 3. Concepts
BRAM Configuration Editor
The BRAM Configuration Editor provides a simplified graphical wizard for creating a BRAM configuration
file (.acxip). This editor allows the user to generate the required configuration files for design with the
embedded PLLs. See
By default, the BRAM Configuration Editor is included in the IP Configuration perspective
(Window→Open Perspective→IP Configuration) (
). The BRAM configuration information fits into a
single page, unlike more complicated IP editors.
Once the user has configured the BRAM to meet their requirements, and the BRAM Configuration Editor
has determined that there are no errors in the configuration, the user may choose to generate their IP design
files (see
Generating the IP Design Files
IP Diagram
The IP Diagram View for the BRAM shows live information about the current configuration in the Editor,
including which inputs and outputs are currently active.
Figure 3.12: Example IP Module Diagram for BRAM
23
