Editors
Chapter 3. Concepts
Advanced PLL Editor Port Names Page Options
Option
Description
Input Ports
Name for Input ”refclk”
The desired name for the reference clock input
signal in the generated RTL.
Name for Input ”fbclk”
The desired name for the feedback clock input
signal in the generated RTL. This option is not
available when the PLL is in Pure Internal
Feedback Mode.
Phase inc[0-3] Input Port Name
The desired name for the phase inc input signal
(for the appropriately numbered clock output) in
the generated RTL.
Output Ports
Clkout Output [0-3] Port Name
The desired name for the PLL clock output in the
generated RTL.
Name for Output ”pll lock”
The desired name for the PLL’s lock indication
output signal in the generated RTL.
