draw oval
Chapter 5. Tcl Command Reference
draw oval
draw oval
<
x
> <
y
> <
width
> <
height
>
[-layer
<
arg
>
] [-id
<
arg
>
] [-rgb
<
args
>
] [-batch] [-thickness
<
arg
>
] [-fill]
This command allows you to draw a custom oval on the GUIs layout view.
Argument
Required/Optional
Description
<
x
>
Required
The required
specifies the upper-left x
coordinate for the oval.
<
y
>
Required
The required
specifies the upper-left y
coordinate for the oval.
<
width
>
Required
The required
argument specifies the width of
the oval.
<
height
>
Required
The required
argument specifies the height of
the oval.
[-layer
<
arg
>
]
Optional
The optional -layer
option specifies the drawing
layer for the oval. If this option
is not used, the top layer (5) will
be used. Using a value of 0 will
draw on the background.
[-id
<
arg
>
]
Optional
The optional -id
specifies a unique id for the oval.
If this option is not used, a
unique id will be automatically
generated and returned by the
command.
[-rgb
<
args
>
]
Optional
The optional -rgb
specifies the rgb color value for
the oval as a 3 element list of
integers red green blue. If this
option is not used, the color blue
will be used.
[-batch]
Optional
The optional -batch option
causes the GUI to not refresh
after this command. This is
useful when running many
draw commands in a row.
Afterwards, refresh drawing can
be called.
[-thickness
<
arg
>
]
Optional
The optional -thickness
<
pixels> option specifies the
oval thickness in pixels. If this
option is not used, a thickness of
1 will be used.
