draw arc
Chapter 5. Tcl Command Reference
<
width
>
Required
The required
argument specifies the width of
the arc.
<
height
>
Required
The required
argument specifies the height of
the arc.
<
startAngle
>
Required
The required
argument specifies the starting
angle of the arc.
<
arcAngle
>
Required
The required
argument specifies the angle of
the arc.
[-layer
<
arg
>
]
Optional
The optional -layer
option specifies the drawing
layer for the arc. If this option is
not used, the top layer (5) will be
used. Using a value of 0 will
draw on the background.
[-id
<
arg
>
]
Optional
The optional -id
specifies a unique id for the arc.
If this option is not used, a
unique id will be automatically
generated and returned by the
command.
[-rgb
<
args
>
]
Optional
The optional -rgb
specifies the rgb color value for
the arc as a 3 element list of
integers red green blue. If this
option is not used, the color blue
will be used.
[-batch]
Optional
The optional -batch option
causes the GUI to not refresh
after this command. This is
useful when running many
draw commands in a row.
Afterwards, refresh drawing can
be called.
[-thickness
<
arg
>
]
Optional
The optional -thickness
<
pixels> option specifies the arc
thickness in pixels. If this option
is not used, a thickness of 1 will
be used.
[-fill]
Optional
The optional -fill option specifies
whether the arc should be filled
with color or not. If this option is
not used, the arc will be hollow.
