Chapter 3. Concepts
(configured in Preferences)
This link, when selected, will bring up the
, allowing the user to configure the
qsub
command-line options
which will be used when submitting jobs to the GridEngine.
When the Parallel Job Count is set to the minimum value of 1, all selected implementations will be executed
sequentially, one at a time. A value of 2 would cause all selected implementations to be queued, and
then the first two queued implementations would be allowed to execute at the same time. As soon as
an implementation completes its flow execution, the next queued implementation starts flow execution
and the
is updated with information gathered from the just-completed
implementation.
By default, ACE executes implementations in parallel by starting a background process on the host
workstation for each implementation. In this case, the effectiveness of parallel implementation execution
will naturally be limited by the resources of the host workstation.
Alternately, ACE may execute
the implementations in processes distributed among multiple hosts via an external GridEngine, which
will theoretically allow for greater parallel compute resources.
The GridEngine submissions are via
the GridEngine command-line executable ”
qsub
”, which may be configured via the
, reached by following the (configured in Preferences) hyperlink.
See
Configuring the Execution Queues
for more details regarding parallel implementation execution,
configuration, and GridEngine support.
Multiprocess Flow Management
This section allows the user to alter how far the flow will be executed for the multiprocess implementations.
Multiprocess Flow Management Controls
Name
Description
Stop Flow After
Allows the user to override standard flow behavior, and stop the flow early - the
flow step selected becomes the final flow step executed by all multiprocess
implementations. Useful when steps late in the flow are known to fail with
reported errors, but the user still wishes to run multiple implementations through
earlier parts of the flow.
Force Selected
Flow Step to be
Enabled
When optional flow steps are selected as the final flow step (in the Stop Flow After
drop-down list), this checkbox can ensure that the selected step is always enabled
in the multiprocess flows, regardless of the flow step’s current enabled state in the
See also:
Configuring the Desired Flow to be Followed by the Selected Implementations
Select Implementations
This section allows the user to select which implementations they wish to execute (implementations derived
from
will be created if selected), start or stop the execution of all selected implementations, and
provides simple execution state feedback.
See
Selecting the Implementations to be Run in Parallel
Canceling Background Execution
Selecting the Implementations to be Generated and Run in Parallel
, and
Generating Option Set Implementations and Starting Background Execution
for more usage details.
Select Implementations Controls
Name
Description
