Understanding Report Templates Chapter 5
Rockwell Automation Publication RPTEXP-UM001H-EN-P-June 2014 67
The drillthrough hierarchy: none.
Calculations used by Report Expert to obtain values in the resulting
report:
• Duration = End Time - Start Time
The State Summary report template displays aggregated state data.
This report template allows you to determine how often and for
how long states occurred during the manufacturing process.
Query: State Summary
The fields of the report template grid:
Item Description
State Count The number of states that occurred during the reporting period.
Total Duration The total time (HH:MM:SS.mmm) in the reporting period during
which an event or state was occurring.
Min Duration The shortest event or state occurrence.
Max Duration The longest event or state occurrence.
Avg. Duration The average length of event or state occurrences.
Detail Link to a State Detail report for the selected state.
The values of the report template and other report templates to
which the values link using the drillthrough hierarchy:
Click a value in this column: To display this report template:
State Count State Summary (grouped by the next value
in the drillthrough hierarchy)
Total Duration
Min Duration
Max Duration
Avg. Duration
Detail
State Detail
The report template bar charts: State Count and Total Duration.
State Summary
