Understanding Report Templates Chapter 5
Rockwell Automation Publication RPTEXP-UM001H-EN-P-June 2014 45
The report does not support any grouping.
NOTE
Due to a large amount of data that can be displayed with this report we
recommend that you filter your data thoroughly to shorten the report
generation time, and/or limit the number of records to be returned with
the EventDetailExtRowLimit setting (page 138) available in the
RptSetting table.
Query: EventDetailExt.
The fields of the report template grid:
Item Description
Line
Workcell A level of the plant model (which is constructed by enterprise, site,
area, line, and then work cell).
Event Category The category of the event.
Event Name The name of the event.
Event Severity The numeric severity level assigned to the event.
Start Time The date and time that the event or state started.
End Time The date and time that the event or state ended.
Duration The length of the event, calculated as the difference between start
time and end time and displayed using the format
HH:MM:SS.mmm. The calculation for this field is:
Duration = End Time - Start Time.
Start Value The value collected at the start of the event.
End Value The value collected at the end of the event.
Shift Start Time The start time of the shift during which the data was collected.
Shift Number The number of the shift.
Shift Name The name of the shift.
Record State The numeric state of the database record.
Event During
Scheduled Time Information whether the event occurred during the scheduled time.
Event Start Num The numeric value collected at the start of the event.
Event End Num The numeric value collected at the end of the event.
Event During Num A numeric information on the event calculated as the difference
between Event End Num and Event Start Num. The calculation for
this field is:
Event During Num = Event End Num – Event Start Num.
