Understanding Report Templates Chapter 5
Rockwell Automation Publication RPTEXP-UM001H-EN-P-June 2014 53
Item Description
Avg. Duration/Event
End Num The average length of event or state occurrences (for grouping
rows) / The numeric value collected at the end of the event (for
detail rows).
The drillthrough hierarchy: none.
The Event Summary report template displays aggregated event data.
This report template allows you to determine how often and for
how long events occurred during the manufacturing process.
Query: Event.
The fields of the report template grid:
Item Description
Event Count The number of events that occurred during the reporting period.
Total Duration The total time (HH:MM:SS.mmm) in the reporting period during
which an event or state was occurring.
Min. Duration The shortest event or state occurrence.
Max. Duration The longest event or state occurrence.
Avg. Duration The average length of event or state occurrences.
Detail Link to an Event Detail report for the selected event.
The values of the report template and other report templates to
which the values link using the drillthrough hierarchy:
Click a value in this column: To display this report template:
Event Count Event Summary
Total Duration Event Summary
Min. Duration Event Summary
Max. Duration Event Summary
Avg. Duration Event Summary
Detail Event Detail
The report template bar charts: Event Count and Total Duration.
Event Summary
