Understanding Report Templates Chapter 5
Rockwell Automation Publication RPTEXP-UM001H-EN-P-June 2014 59
• A = AvailableTime
If you group a report by work cell, using the Production report
template allows you to determine the production success of a single
work cell or to compare the production successes of multiple work
cells.
Query: Performance.
The fields of the report template grid:
Item Description
Good Parts The number of good parts produced.
Scrap Parts The number of parts rejected due to poor quality.
Total Parts The total number of parts produced.
Ideal Parts The total number of parts that could have been produced in the
available time. The calculation for this field is:
IdealParts = AvailableTime / IdealCycleTime.
Ideal % A measurement of how close the activity area was to ideal
performance. The calculation for this field is:
Ideal % = GoodParts / IdealParts. It calculates the percentage of the
ideal part count that was actually produced.
Scrap % The percentage of total parts produced that were rejected due to
poor quality. The calculation for this field is:
Scrap % = ScrapParts / TotalParts.
Running Time The number of seconds the machine was in a running state.
Uptime % The percentage of available time that the machine was actually
running. The calculation for this field is:
Uptime % = RunningTime/AvailableTime.
The values of the report template and other report templates to
which the values link using the drillthrough hierarchy:
Click a value in this column: To display this report template:
Good Parts Production
Scrap Parts Quality
Total Parts Production
Production
