Chapter 8 Editing Event and Production Data
108 Rockwell Automation Publication RPTEXP-UM001H-EN-P-June 2014
Item Description
Plant Model Filter The type of Plant Model Filter criteria (page 90) applied to the data.
Time The type of Date/Time/Shift criteria (page 77) applied to the data.
Sort The type of Sorting criteria (page 88) applied to the data.
Filter The type of Filtering criteria (page 91) applied to the data.
In the Activity area details panel, you can view the current
information on the performance of the selected work cell, for which
the parts were counted.
The Activity area details panel contains the following items:
Item Description
Start Time
End Time The time at which the production of the parts
started/ended.
Part Id The ID of the part produced in the specified period of time.
Good Parts The number of good parts produced.
Scrap Parts The number of parts rejected due to poor quality.
Total Parts The total number of parts produced in the specified period
of time (i.e., the sum of good parts and scrap parts).
When editing the number of parts, Total Parts should not
exceed Max Parts.
Max Parts The maximum number of parts which could have been
produced in the specified period of time. The number is
calculated as the multiplication of Ideal Cycle Time and
Running Time.
Records The number of records written in the FactoryTalk Metrics
database for the selected production data.
Shift The name of the shift.
Running Time The period of time between the start and end time during
which the work cell was in the Running state.
Available Time The period of time between the start and end time in which
the work cell was in the Available state, as defined in the
work cell’s configuration in FactoryTalk Metrics.
Actual Cycle Time The amount of time in which a single part was actually
produced.
Activity Area Details Panel
