DIN 41 612 · complementary type 3R
Male connectors
Number of contacts
30, 20
Number Contact
Identification of contacts arrangement
Part No. Performance levels according to IEC 60603-2. Explanation chapter 00
3 2 1
● Wrap posts for interfacing selectively gold plated (performance level 3)
1) To be used only for wire wrap termination
d) CTI > 400
w) Wrap posts not for interfacing, no performance level
Male connector
with solder pins
2.5 mm
Male connector
with solder pins
4.0 mm
Male connector
with solder pins
13 mm
Male connector
with press-in pins
5.0 mm
Male connector
with press-in pins
13 mm
Male connector
with wrap posts 1)
13 mm
30 09 29 130 6902
with fixing flange 20 09 29 120 6902
30 09 29 130 6903
with fixing flange 20 09 29 120 6903
30 09 29 130 6577
with fixing flange 20 09 29 120 6577
30 09 29 130 6904
with fixing flange 20 09 29 120 6904
30
09 29 130 6985 w)
09 29 130 6974 ●
with fixing flange 20 09 29 120 6974 ●
with fixing flange 30 09 29 130 6907
with fixing flange, SMC 30 09 29 130 6519 d)
with fixing flange, SMC 30 09 29 130 6520 d)
with fixing flange, SMC 30 09 29 130 6521 d)
without fixing flange 30 09 29 130 6504
without fixing flange 30 09 29 130 6574 ●
without fixing flange 30 09 29 130 6592
without fixing flange 30 09 29 130 6593
without fixing flange, SMC 30 09 29 130 6569 d)
without fixing flange, SMC 30 09 29 130 6570 d)
