Tools for HARTING DIN 41 612 crimp contacts
DIN 41 612 Signal crimp contact type
BC crimp contacts
09 02 000 ....
har-bus ® 64 crimp contacts
02 05 000 ....
Part
number
Female contacts
PL 1 6474 8444 8474 6474 8444 8474 1511 1512 1513 1511 1512 1513
PL 2 6484 8434 8484 6484 8434 8484 2511 2512 2513 2511 2512 2513
Bandoliered contacts: 5,000 pieces / reel X X X X
Bandoliered contacts: 500 pieces / reel X X X X
Individual contacts X X X X
Cable diameter
mm² 0.09-0.5 0.13 mm²
solid wire
0.09-0.5 0.13 mm²
solid wire AWG 28-20 28-20
Hand crimp tool
09 99 000 0075 X X
09 99 000 0248 X X
09 99 000 0627 X X
Hand crimp tool
09 99 000 0620 with insert
09 99 000 0621 X X
09 99 000 0629 X X
Semi automatic crimp tool
09 99 000 0246 with head
09 99 000 0252 X X X X
09 99 000 0628 X X X X
and reel holder 09 99 000 0158 X X X X
Automatic crimp machine type BK
09 98 000 5000 with tools
09 98 000 3004 X X X X
Insertion tool 09 99 000 0100 X X
Removal tool 09 99 000 0101 X X
DIN 41 612 Power crimp contacts
FC crimp contacts
09 06 000 ....
FC 1 FC 2 FC 3
Part
number
Female contacts
PL 1 6474 7474 8474 6471 7471 8471 6472 7472 8472
PL 2 6484 7484 8484 6481 7481 8481 6482 7482 8482
Male contacts
PL 1 9544 – 9554 9541 5541 9551 9542 5542 9552
PL 2 9564 – 9574 9561 – 9571 9562 – 9572
Female contacts for
1 x 1 wire wrap posts
– 6454 – 6464 6451 – 6461 6452 – 6462
Bandoliered contacts: 2,500 pieces / reel X X X
Bandoliered contacts: 250 pieces / reel X X X
Individual contacts X X X
Cable diameter
mm² 0.09-0.25 0.14-0.56 0.5-1.5
AWG 28-24 26-20 20-16
Hand crimp tool
09 99 000 0075 X
09 99 000 0076 X
09 99 000 0077 X
09 99 000 0191 X X X
09 99 000 0247 X
09 99 000 0119 X
09 99 000 0120 X
Hand crimp tool
09 99 000 0620 with insert
09 99 000 0621 X
09 99 000 0622 X
09 99 000 0623 X
Semi automatic crimp tool
09 99 000 0246 with head
09 99 000 0249 X X
09 99 000 0250 X X
09 99 000 0251 X X
and reel holder 09 99 000 0158 X X X
Automatic crimp machine type BK
09 98 000 5000 with tools
09 98 000 3005 X
09 98 000 3006 X
09 98 000 3007 X
Insertion tool 09 99 000 0088 X X X
Removal tool 09 99 000 0087 X X X
